产品描述
1.额定电流 | 3.0AMP |
2.接触电阻 | 10mΩ Max |
3.介电强度 | Min 1000VRMS |
4.机械寿命 | Min 500 cycles |
5.配合销 | ∅0.40 To ∅0.66mm or 0.50SQ |
6.效力 | Polished Steel Gauge ∅0.47mm |
7.插入物 | 200g Max/Pin Withdrawal:60g/pin |
8.工作温度 | ﹣40℃ to +105℃ |
9.套筒 | Brass CuZn36Pb3(C36000) Sn over Ni |
10.接触夹(4 Finger) | BeCu(C17200) Au Sn over Ni |
11.绝缘材料 | PPS+30%GF(UL94V-0) |
